Outlet temperature:
Max. 160°C
Heat transfer fluid:
Water
Filling quantity: 3,0 I
Expansion volume: 2,0 I
Heating capacity at 400V:
Standard: 17 kW
Cooling capacity:
Cooler type: SK
Max. 66 kW
Cooler type: 2SK
Max 78 kW
at outlet temperature 150°C
Pump capacity:
Type: SM82
Flow rate: max. 80 l /min
Power consumption: 2,8 kW
Pressure: max. 9 bar
Control:
Type: RT100
Measuring mode: Pt100
Operating voltage:
Standard: 400/50 3PE V/Hz
Connections:
Outlet/inlet: G3/4″
Cooling water supply: G3/4″
Dimensions:
Width: 507 mm
Height: 1173 mm
Depth: 1479 mm
Weigth:
Standard: 280 kg
Colour:
Standard: 9006/7016 RAL
Ambient temperature:
Max. 40 °C
Noise level:
max. 70 db (A)
