Outlet temperature:
Max. 300°C
Heat transfer fluid:
Oil
Filling capacity: 24 I
Expansion volume: 20 I
Heating capacity at 400V:
Standard: 20 kW
Standard: 40 kW
Cooling capacity:
Cooler type: 1K
Max. 160 kW
at outlet temperature 280°C
Pump capacity:
Type: FM65
Flow rate: max. 90 l /min
Power consumption: 2,8 kW
Pressure: max. 10 bar
Control:
Type: RT100
Measuring mode: Pt100
Operating voltage:
Standard: 400/50 3PE V/Hz
Connections:
Outlet/inlet: G3/4″ IG
Cooling water supply: G3/4″
Dimensions:
Width: 541 mm
Height: 1356 mm
Depth: 1474 mm
Weight:
Standard: 365 kg
Colour:
Standard: 9006/7016 RAL
Ambient temperature:
Max. 40 °C
Noise level:
max. 70 db (A)
